EVE LF100LA — 100 Ah LiFePO₄ Cell (Grade-A, 3.2 V)
EVE LF100LA — 100 Ah LiFePO₄ Cell (Grade-A, 3.2 V)
High-energy, long-life LiFePO₄ prismatic cell with robust aluminum build, 4,000+ cycle life, 1C continuous and 2C pulse current, and wide temperature tolerance—ideal for solar, EV, marine, and backup power projects.
Original price was: 6,100.00৳ .5,400.00৳ Current price is: 5,400.00৳ .
Out of stock
Battery Cell, Lithium BatterySpecifications
| Feature | Specification |
|---|---|
| Model | LF100LA / LF100MA |
| Chemistry | LiFePO₄ (LFP) |
| Nominal Voltage | 3.2 V |
| Nominal Capacity | ≥ 100 Ah (100 Ah typical) |
| Min. Energy | ~320 Wh |
| Internal Resistance | ≤ 0.5 mΩ |
| Cycle Life | ≥ 4,000 cycles @ 1C/1C, 80 % DoD |
| Standard Charge/Discharge | 0.5C (≈50 A) |
| Max Continuous C-rate | 1C (≈100 A) |
| Max Pulse (30 s) | 2C (≈200 A) |
| Charging Cut-Off Voltage | 3.65 V per cell |
| Discharge Cut-Off Voltage | 2.5 V (T > 0 °C); 2.0 V if T ≤ 0 °C |
| Recommended SOC Range | 10 % – 90 % |
| Operating Temperature (Charge) | 0 °C – 55 °C |
| Operating Temperature (Discharge) | –20 °C – 55 °C |
| Storage Temperature | Short-term: –20 °C – 45 °C; Long-term: 0 °C – 35 °C |
| Self-Discharge Rate | ≤ 3 % per month @ 25 °C |
| Dimensions (HxWxT) | 118.5 × 160 × 50.1 mm ± tolerances |
| Weight | ~1.98 kg ± tolerance |
| Encapsulation Mode | U-shaped aluminum shell with explosion-proof valve |
Why Choose EVE LF100?
-
Long-lasting: 4,000+ cycle life at 1C means years of reliable service—even in heavy-duty applications.
-
Safe & Robust: Aluminum encasement with valve protection ensures structural safety and thermal management.
-
High Power Handling: Capable of both continuous 100 A output and short pulses of 200 A—great for high-demand systems.
-
Compact & Lightweight: Slim design (50 mm thick) and lightweight (~2 kg) for efficient pack integration.
-
Grade-A Quality: Often delivered with matched voltage, IR, and includes busbars/bolts.
Applications & Use Cases
-
Solar Energy Storage Systems (ESS)
-
Electric Mobility: EVs, golf carts, forklifts, scooters
-
Backup Power: UPS, telecom towers, off-grid solutions
-
Marine & RV Systems: High-reliability energy source for harsh conditions
Warranty is voided by:
-
Improper handling, including transportation, storage, installation, or wiring outside official guidelines.
-
Unauthorized modifications or disassembly.
-
Use outside official specifications (e.g., improper BMS, overcurrent, incorrect voltage limits).
-
External damage (surges, floods, fire, physical trauma, or environmental extremes).
